TATA Durashine
DURASHINE™ range of colour coated steel products will come with strong credentials such as :-
- Aesthetic appeal
- Greater durability
- Higher strength
- Better thermal efficiency
- Light-weight and strong
- Greater spanning capability
- Zinc coating to provide longer life
- No welding at site
- Lower maintenance cost
- Easy installation
  |
Durashine Roof
|
|||||
 |
Total Coated Thickness (mm)
Sheet Length (mm)
Effective Cover Width (mm)
Overall Width (mm)
Min. Roof Slope (Degree)
|
0.45
2440(8ft), 3050(10ft), 3660(12ft), 4270(14ft), 4880(16ft), 6100(20ft)
Nominal 1015
Nominal 1072
3
|
|||
Durashine Wall
|
|||||
 |
Total Coated Thickness (mm)
Sheet Length (mm)
Effective Cover Width (mm)
Overall Width (mm)
|
0.45
2440(8ft), 3050(10ft), 3660(12ft), 4270(14ft), 4880(16ft),
Nominal 1110
Nominal 1150
|
|||
Durashine Guard hut
|
|||||
 |
Length
Width
Height
|
1.80 mtr (minimum)
1.20 mtr
2.28 mtr (front)
|
|||
Durashine Tile
|
|||||
 |
Total Coated Thickness (mm)
Sheet Length (mm)
Effective Cover Width (mm)
Overall Width (mm)
Min.Roof Slope (Degrees)
|
0.45
2440, 3200,3960
Nominal 421
Nominal 505
5
|
|||
Durashine Purlines
|
|||||
 |
Purlin Section
Z10010
Z15015
|
Thickness (mm)
1.0
1.5
|
Depth/Web (mm)
102
152
|
Flange Top/Bottom
53/49
65/61
|
Standard Length - metres
6
6
|
